APEL™

Cyclo olefin copolymer

A multifunctional and transparent resin (cyclo olefin copolymer) independently developed by Mitsui Chemicals.

Transparent, high refractive index, low birefringence, stable dimensions, heat-resistant, resistant to chemicals, stiff, superior moldability, moisture-proof.


Summary

APEL™ is a cyclo olefin copolymer (COC) that integrates the performance of polyolefin resins and that of amorphous resins. With the highest refractive index among the amorphous polyolefins, APEL™ is low in optical anisotropy and essentially low in birefringence. This makes it ideal for optical plastic lenses. With excellent moisture-proof properties, resistance to chemicals, and non-attachment characteristics, APEL™ is also used for medical packaging. Its many functions and superior characteristics create new potential for transparent materials.

APEL™
APEL™

Optical characteristics

High refractive index and low birefringence.

APEL™ cyclo olefin copolymer is ideal for high-transparency optical plastic lenses.

Camera lens unit for mobile phones Camera lens unit for mobile phones
Pickup lens unit for optical disk Pickup lens unit for optical disk
Extrusion molding sheets Extrusion molding sheets
Injection molding plates Injection molding plates
Moisture-proofness

With the lowest moisture permeability coefficient among transparent resins, APEL™ cyclo olefin copolymer is perfect for moisture-proof containers and films.

Resistance to chemicals

APEL™ cyclo olefin copolymer is chemically stable and exhibits a high level of resistance to acid, alkali and polar solvents.

Resistance to chemicals
Resistance to chemicals
Electrical characteristics

APEL cyclo olefin copolymer has superior electrical characteristics inherent to polyolefins. It also excels in high-frequency characteristics.

Stability in dimensions

Amorphous qualities give APEL cyclo olefin copolymer high levels of dimensional accuracy and freedom from dimensional variation due to water absorption.

Outstanding resistance to heat

APEL cyclo olefin copolymer is low in temperature dependency as part of mechanical properties. It is possible to freely control its heat-resistance by changing the copolymerization ratio between ethylene and cyclo olefin.

Moldability

APEL cyclo olefin copolymer’s fluidity can be freely controlled by adjusting the molecular weight. This enables enhanced fluidity.

Lenses for mobile phones, cars and for digital cameras, pickup lenses for optical disks, f-theta (fθ) lenses for laser beam printers, lenses for projectors, press-through package (PTP) sheets, pre-filled syringes, bottle for medicine, bottle for cosmetics, cells for analysis, shrink tubes, shrink films, easy cut films for food packages, electric and electronic components, containers for transport of electronic components, pump components, etc.

Optical characteristics

Exhibiting an extraordinarily low level of birefringence, it also has a higher refractive index than polymethyl methacrylate (PMMA).

Comparison in light transmittance
Comparison in light transmittance
Comparison of Stress Optical coefficient
Comparison of Stress Optical coefficient
Comparison of resins for optical applications in terms of characteristics

The low level of birefringence, high refractive index and transparency derive from a molecular structure that has both stiff main chains and bulky side chains. With their high density, the stiff main chains exhibit a high refractive index, while bulky side chains lead to transparency due to their amorphous quality. The molecule itself has poor anisotropy that results in the low level of birefringence.

Comparison of resins for optical applications in terms of characteristics
Comparison of refractive index and Abbe's number

APEL™ has a higher refractive index than PMMA, but their Abbe's number is almost equivalent.

Comparison of refractive index and Abbe's number
Dependence of the refractive index on wavelength and temperature
Dependence of the refractive index on wavelength and temperature
Moisture-proof characteristics

With the lowest moisture permeability coefficient among the transparent resins, it is perfect for moisture-proof bottles and PTP sheets.

Comparison with polypropylene (PP) in terms of moisture-proofness

APEL™ displays outstanding moisture-proof properties.

Comparison with polypropylene (PP) in terms of moisture-proofness
Comparison of resins in terms of moisture-proofness



Comparison of resins in terms of moisture-proofness
Resistance to chemicals

It is highly resistant to acid, alkali and polar solvents. This property is requisite to cells for analysis and PTP sheets.

Comparison of transparent resins in terms of resistance to chemicals
Comparison of transparent resins in terms of resistance to chemicals ○ : Resistant and compatible △ : Attention required × : Not resistant and compatible
Heat resistant stiffness

Given its mechanical characteristics, its temperature dependence is so low that it retains a high level of stiffness even at high temperatures.

Storage elastic modulus (in Pa)
Storage elastic modulus (in Pa)
Gas barrier properties

It is superior to polyethylene and polypropylene in gas barrier properties.

Gas barrier properties
Lineup of grades
Lineup of grades
Physical properties table
Physical properties table

Optical applications

APEL™ is ideal for optical plastic lenses that need to have a low level of birefringence, a high refractive index, transparency, and high dimensional accuracy.

  • Image pickup lenses for mobile phones
  • Image pickup lenses for digital cameras
  • Pickup lenses for optical disks
  • F-theta (fθ) lenses for laser beam printers
  • Lenses for projectors
Optical applications
Optical applications
Optical applications
Optical applications
Medical applications

APEL™ is used in PTP sheets that need to be very resistant to moisture. Enabling gamma-ray sterilization and autoclave sterilization, it has also been adopted for cell containers for analysis, as they must be resistant to chemicals and have non-attachment characteristics.

  • PTP sheets for pills
  • Pre-filled syringes
  • Bottles for medicine
  • Bottles for cosmetics
  • Cells for analysis
Medical applications
Medical applications
Medical applications
Packaging applications

APEL™ is perfect for packaging films and other applications that have to be tearable and shrinkable.

  • Shrink tubes and shrink films
  • Easy-cut films for food packages
Packaging applications
Other applications

APEL™ is used for precision-formed products, which benefit from its low water absorption properties and chemical resistance.

  • Electrical and electronic components
  • Containers for transport of electronic components
  • Pump components
Other applications
